HGA101 - Superheated Steam Generator 1kW SIMPLE - High temperature high quality steam generator

Superheated Steam Generator
Instant High Temperature Steam

HGA-S and HGA-H Models (1- 500 kW)

Instant high quality steam generation
- S- Models up to 450°C temperature (ask MHI about our 100-1500°C steam generators-CX models)
- H-Models up to 700°C temperature (ask MHI about our 100-1500°C steam generators CX Models)
- 1 atmospheric pressure (standard) or higher as required (optional feature)
Plug-and-play system
- Call MHI for available flow rates
1kg/hr and upward to 100kg/hr.
120V/220V standard plug-in models. 3 phase 440V models available.
Industry tested controls available
- Optional MHI BPAN-O-2010 controller provides enhanced closed-loop feedback process control. BPAN control panels are now one of the best available panels. Use with standard MHI DACS for data acquisition and control.
Options include up to 1500°C steam with steam chamber.
Typical Process Steam Chamber (see example model HGA-S-CX1300)
Advanced safety features - call MHI for more details. Safety thermocouples are integrated.
Full integrated control including OPTIONAL oxygen sensors in integrated models.
Light-weight, Safety enhanced, Height adjustable, Easy mounting, Boilerfree™

protected by several patents and pending patents. Trademarks on this page belong to Micropyretics Heaters International Inc.

Picture below shows model number HGA-S-CX1300 (complete system).

Dry steam generation
- upto 1300°C temperature
- 1 atmospheric pressure operation
Plug-and-play system
- 1/4” NPT outlet for easy connection to existing piping
- Quick-disconnect water inlet
- Standard integrated K-type process thermocouples
- All components 120V or 220V standard electrical plug-in
High temperature steam chamber available
- Use as steam reaction chamber or pass-through steam enhancer
- Integrated pressure relief valve for safe operation
Approxamitely 2kW+ total system power for research use (this model). Higher power industrial units available.
Standard peristaltic pump
- Enables metered water input
- Fully adjustable range from 0-32 mL/min (for this model). Higher flows available.
MHI brand industry-tested control systems
- MHI BPAN-O-Plus-2010™ Control Panel
- Provides enhanced closed-loop feedback process control
- Over-temperature protection with integrated over-temperature thermocouple
Compact design
All stainless steel construction
High Efficiency
